Design

Qbiss One Design

Explore the endless design possibilities.

Endless design possibilities

Qbiss One is one of the most modern, smoothest and flattest metal facade solutions in its class.

Qbiss One is distinguished by its unique and patented rounded corner element, which eliminates the need to cut, weld, or fold the panel which is so often an area of weakness, failure and eventual discoloration on traditional metal rainscreens.

Qbiss One is available in flat or curved options, for even greater flexibility, and with either recessed or flush joints, or a combination of the two. The Qbiss One element can also be installed in a variety of different orientations including vertical, horizontal, stacked or off-set for a ‘brick-like’ effect. Combinations of these are also possible to present the widest design possibilities and allow constructions that are truly individual.

UNIQUE FLATNESS, LARGER SIZES

Clean, smooth and modern façade designs are possible with Qbiss One, which excels in its extreme flatness at any element size.

With lengths from 530 mm up to 6,500 mm Qbiss One provides longer facade elements than conventional metal rainscreens, which are typically standard up to 3 metres.

Qbiss One flattest wall in its class

JOINT OPTIONS

Qbiss One system allows the combination of various permutations of recessed and flush joints.

Joint option type B-B
Joint option type F-BF
Joint option type F-B
Joint option type B-BF
Joint option type BF-B
Joint option type BF-BF

ARTME FACADE DESIGN













ArtMe is the most modern, unique, high-tech facade surface treatment that allows literally unlimited shapes, patterns and visual effects to be expressed on the façade surface for dramatic, individual and creative results.

From designs and pictures to inscriptions, logos, brands and bespoke creations, ArtMe makes this possible without the need for adhesives, additional elements or structural devices.

ArtMe uses a highly controlled, 3D-forming technology, which is being used for the first time on completed façade elements with pre-coated steel-sheet surfaces. Recognizing the importance of product performance, the original integrity and characteristics of the wall elements are preserved without compromise.

The technology behind the façade surface re-shaping allows any design of choice to be chosen. Although there is the option to select pre-designed patterns

More about ArtMe

Installation options

VERTICAL BRICK INSTALLATION

Vertical Brick structured installation enables individual façade elements to be connected vertically. Variety can be achieved by installing modular façade elements with a shift in a horizontal direction.

HORIZONTAL INSTALLATION

This installation presents the classic and most commonly used orientation type. The horizontal modular façade system is composed of individual façade elements, joined in the horizontal direction (longitudinal) with a tongue & groove stack system, and fixed to the supporting structure in a vertical direction (transversal). Longitudinal joint sealing is accomplished using gaskets, integrated in both longitudinal joints; transversal joints (vertical joints) are sealed with a specially profiled gasket.

OFFSET OR SHIFTED HORIZONTAL INSTALLATION

So-called "brick-built installation" is the latest innovation to hit the façade element market. This solution not only enables a symmetrical shift (the vertical joint in the middle of the upper or lower façade element is offset) but also means that vertical joints can be located anywhere on the longitudinal axis of the neighbouring horizontal façade elements.

HORIZONTAL ASYMMETRICAL INSTALLATION

This innovative installation offers another modern facade option to architects who may be seeking to add further individuality to their projects. With asymmetrical structured installation, the horizontal axis is completely aligned along the whole width of the building, whilst the verticals are aligned according to a random installation. This way, the building envelope creates a modern dynamism, highlighting the form of the building and other architectural features.

VERTICAL INSTALLATION

Classical vertical modular façade system is composed of individual façade elements, joined in a vertical direction (transversal) with a tongue and groove system, and fixed to the supporting structure in a horizontal direction (longitudinal). Longitudinal joint sealing is accomplished using gaskets, integrated in both longitudinal joints, with additional sealant in the groove of the EPDM corner element; transversal joints (horizontal joints) of the element are sealed with a specially profiled gasket.

VERTICAL BRICK INSTALLATION

Vertical Brick structured installation enables individual façade elements to be connected vertically. Variety can be achieved by installing modular façade elements with a shift in a horizontal direction.

HORIZONTAL INSTALLATION

This installation presents the classic and most commonly used orientation type. The horizontal modular façade system is composed of individual elements, joined in the horizontal direction (longitudinal) with a tongue & groove stack system, and fixed to the supporting structure in a vertical direction (transversal). Longitudinal joint sealing is accomplished using gaskets, integrated in both longitudinal joints; transversal joints (vertical joints) are sealed with a specially profiled gasket.

COLOURS

Qbiss One guarantees ultimate corrosion protection for up to 30 years. Terms and conditions apply.

Range of Colours

Special metallic
Silver
Light Silver
Dark Silver
Light graphite
Solid colours
White
Gray White
Light grey
Cream
Basalt grey
Sapphire Blue
Traffic red
Anthracite
Black

Colorcoat Prisma® Elements*
Sirius Sparkle
Orion Sparkle
Zeus Sparkle
Seren White
Seren Silver
Seren Gold
Seren Midas
Seren Copper
Seren Titan
Seren Black
Anthracite Solet

* Colorcoat Prisma and Seren are trademarks of Tata Steel UK Limited

Bespoke solutions and materials**
Quadro Lucido
Dots Lucido
2WL Lucido
5WL Lucido
Pelle Lucido




** Availability and application shall be discussed with Trimo technical department.

VERSATILE DESIGN

Materials and looks

  • Steel
  • Stainless steel
  • Carbon, wooden look

Colour options

  • One colour for the whole building
  • Different colours of elements organised in a random pattern or in large colour surfaces
  • Different colours of shadow line

*Other colours are available upon request.
