Technical data

Qbiss One Technical data

Look at the technical specifications, guarantee information and a wide range of performance certificates.

TECHNICAL SPECIFICATION


Use External walls, internal walls and ceilings
Panel thickness (mm) 80 - 250
Cover width (mm) 600 - 1200
Length (mm)* From 500 up to 6500
Max. achievable fire resistance (EN 14509) EI 45 - EI 120
Thermal transmittance (W/m2 K) 0.50 - 0.15
Insulant core Non-combustible mineral wool Class A1
Coating Standard coating PVDF or PUR/PA
External facing - profile Steel sheet, stainless steel, thickness: 0.70; G
Internal facing - profile Steel sheet, stainless steel, thicknesses: 0.50, 0.55, 0.60, 0.70; G, S, V, V2, M, M3
Reaction to fire A2-s1, d0
Water permeability (Pa - wall) 1200
Air permeability (C (m3 /Pa*s);n) C = 0.0046; n = 0.970
Water vapour permeability Impermeable
Airborne sound insulation: Rw(C:Ctr) 30 (-1;-3) (dB)

* Qbiss One elements are differentiated based on type of mineral wool being used, depending on thermal insulation requirements and structural spanning needs.

For most used element types (1,2,3,4), the minimum length of the element is 500mm. Qbiss One with all other element types (5,6,7,8,9,10,11 and 12) spans from 550mm to 6475mm.

Calculated according to EN 14509 standard without consideration of longitudinal joint losses.

For specific project data refer to Technical CE specification data and contact Trimo Technical Support

More detailed technical data is available in Qbiss One Book.

GUARANTEES, INSURANCE

Insurance

Qbiss One façade system has been tested and approved to Factory Mutual (FM4880, FM4881) and Loss Prevention Certification Board (LPS1208 – fire resistance of constituent materials and LPS1181 - spread of flame) standards to comply with property insurers risk requirements.

TECHNICAL SUPPORT

Trimo ensures that accurate and comprehensive information is always available because the company knows that the essence of a successful project lies in the detail.

Trimo’s team of experienced specialists ensures precise, timely and quality technical information. A selection of useful and rainscreen cladding details information for architects and designers are available on request.

Trimo also welcomes your opinions, observations and questions and will do its best to provide answers as quickly as possible.


For technical information:

technical@remove-this.trimo-group.com

For commercial inquiries:

qbiss.one@remove-this.trimo-group.com

CERTIFICATES

At Trimo, quality and excellent technical characteristics of itsprefabricated envelopes, exterior wall panels, roofs and complete solutions are supported by numerous certificates. These help the company fulfil different demands, from business processes to legal restrictions as well as the conditions that are set by insurance companies all over the world.

The acquired and attested certificates for business processes:
For a quality management system according to ISO 9001:2015.
For an environment management system according to ISO 14001:2015.
For occupational health and safety management systems according to ISO 45001:2018.



See certificates library
