Trimoterm Power T
Trimoterm Power T are roof and facade panels with much higher thermal insulation than traditional products. In fact, Trimoterm Power T can reach a U-value down to 0.16 W/m2K, and up to 10 % higher thermal insulation.
Trimoterm Power S
Trimoterm Power S are long spanning facade panels, which reduce the need for secondary steel construction. Frame-to-frame spanning capability is up to 10 metres.
Trimoterm Perform R
Trimoterm Perform R is a high-quality façade and roof system that can be fitted to almost any building and is suitable for internal and external applications.
Trimoterm Perform C
Trimoterm Perform C is a versatile, robust and compact façade and roof system where building safety and longevity are paramount. Furthermore, Trimoterm Perform C is made of carefully selected materials to meet the highest national demands of different markets.
Trimoterm Acoustic panels for external and partition walls serve as exceptional protection against noise hazards as well as contributing to the well-being of everyone in the environment. In addition to the standard characteristics of the Trimoterm FTV panels, the acoustic panels also have excellent sound absorbing characteristics. A single-sided perforated structure enables sound absorption of DLα = 8dB and sound insulation of 34 dB for the panel.
Purpose and use
Panels are used in external or partition walls after assessing the sound protection requirements of the project and where there is a demand for absorption and insulation of the construction element. It has to be considered that the steam closure is restricted due to perforation and panels are therefore used for structurally and physically less demanding conditions. Due to their specifics the acoustic characteristics of the panels in relation to thickness change very little.
Trimoterm panels are suitable for the construction of classic and fire rated partition walls, as well as partition walls for clean rooms. They are also used in the construction of ceilings, fireproof ceilings and ceilings for clean rooms.
Classic partition walls
Trimoterm panels are well-fitting and versatile in their use and are excellent for installing in any space as partition walls.
Fire rated partition walls
Trimoterm fireproof panels have excellent fire-resistance characteristics. The fire rated partition wall system consists of the installation of a partition wall onto a concrete construction, installation of fireproof doors, fire-resistant hatches measuring no more than 200 x 200 mm and installation breaches.
Clean room partition walls
Trimo’s solution for clean- and washrooms ensures high-quality materials, well thought-out details, as well as quick and simple installation.
Trimoterm panels of standard modular width of 1,000 mm or 1,200 mm represent the basis of the ceiling system. They are fixed to the supports using a special system, which is placed at specific distances. The prefabricated construction system, with fireproof panels, ensures Trimoterm has strong fire safety, excellent heat and noise insulation characteristics.
Types of ceilings:
- ceilings without special requirements
- fireproof ceilings
- ceilings for clean rooms
Trimoterm Design is a brand new suite of panel aesthetics that bring new visual options to designers and architects.
GlaM is the first panel aesthetic from Trimoterm Design that allows the designer to play with the contrasting features of matt and gloss shine to deliver enormous variety of patterns, in addition to a predesigned Vario Dot pattern, which is also available.
GlaM from Trimoterm Design, provides an attractive look without compromising any of the technical characteristics of the panel. The solution is composed of a complex film, with finishing from high gloss to matt in appearance. GlaM can be used in external and internal applications, such as: exterior facades, interior walls/partition walls and interior ceilings.
- GlaM can be applied to Trimoterm Gladio panels
- Steel sheet thickness 0.7 mm
- Repeatability of design related to panel width
- Design to be concluded at the panel joint area
- Design based on net
Variety of gloss level:
- High gloss: 50 - 80%
- Semi-gloss/Semi-matt: 30 - 40 %
- Matt: 10 - 20%
